Introduction:
Wood slicer belongs to one of the series of wood processing equipment. This machine is also called wood chipper, chipper, wood chipper, wood chipper and chipper grinder. It is widely used in the material preparation section of textile, papermaking, pulping, wood-based panel and other industries. The main raw materials of the machine are logs, small-diameter logs, bamboo, veneer, branches and wood, as well as high-quality industrial wood chips with uniform cutting growth, smooth cut and uniform thickness.
The wood slicer is suitable for trees with diameter less than 120 mm, bark with width less than 160-180 mm and corner material under peeling machine. However, the machine can not cut evenly for too thick (more than 350 mm), too fine (less than 30 mm), too short (less than 250 mm), too thin (less than 5 mm) and irregular raw materials (undispersed stumps, branches, etc.), etc, it can not fully cut the raw materials in the original base Cutting on the basis of the cutting, the bamboo slice with wall thickness less than 5mm is not enough, which has the function of layered cutting
Disc wood slicer is a special equipment for producing high quality wood chips. It can cut all kinds of logs and bamboo, such as pine, miscellaneous wood, poplar, Chinese fir, etc., into uniform pieces. It can also slice various materials such as veneer, veneer, bamboo branch, corn stalk, cotton stalk and other non wood fiber rod. Users can adjust the specification of the wood chips within a certain range according to the needs. The product has regular discharge and high output. It is an ideal equipment for paper mill, wood-based panel, MDF and other industrial production sections and various wood chip production bases. Manufacturers can design and manufacture various specifications of products according to the production capacity of users. The series of disc wood chippers produced by our company are a kind of special equipment for producing high-quality wood chips. They are widely used in the stock preparation section and single chip production base of paper-making, particleboard and medium-sized fiberboard. The main cutting material is logs.
Advantage:
1.easy Operation
2.Low and simple maintenance,
3.long working life and the low.noisy
4.wood chipper would be the best choice for dealing with wood scraps.
5.The machine can process, pine, miscellaneous wood, wood, fir.Because the structure is compact, less covering area, good quality of slice, low power consumption.
Working pricile:
Disc slicer is a kind of wood chipper, which is used to produce high-quality wood chips. The disc chipper is a special equipment for preparing high-quality wood chips. It is suitable for paper mills, particleboard mills, fiberboard factories and chip production bases. It can cut logs, small-diameter logs and other high-quality industrial wood chips with uniform growth, smooth cut and uniform thickness, and can also cut wood and board.
The disc chipper is composed of frame, cutter head, feeding port, cover and electronic system. In order to meet the different requirements of paper-making, fiberboard and particleboard industry, the chip length can be adjusted in a certain range. Disc chipper, compact and reasonable in structure, easy to operate, large production capacity, high qualified rate of wood chips, low energy consumption per unit chip output, is an ideal equipment for producing high-quality wood chips.
Techncal parameters:
| Model | TYQP400 | TYQP600 | TYQP740 | TYQP1150 | TYQP1410 | TYQP1710 | ||||||
| Power(kw/HP) | 11 | 20 | 15 | 22 | 30 | 40 | 55 | 80 | 110 | 150 | 200 | 300 |
| Inlet size(mm) | 150*150 | 180*180 | 220*220 | 320*320 | 450*450 | 620*620 | ||||||
| Max Feeding Dia.(mm) | 130 | 160 | 200 | 300 | 350 | 600 | ||||||
| Rotating speed(r/min) | 900 | 900 | 900 | 900 | 800 | 800 | ||||||
| No.of blades(pcs) | 3 | 3 | 4 | 4 | 6 | 6 | ||||||
| End product size(mm) | 30-50 | 30-50 | 30-50 | 30-50 | 30-50 | 30-50 | ||||||
| Output(t/h) | 0.5 | 1 | 2.2 | 6 | 10-15 | 13-25 | ||||||
| Dimension(m) | 1.5*1*1.3 | 1.7*1.3*1.5 | 1.6*0.8*1.1 | 2.2*0.9*1.3 | 1.5*1*1.3 | 2*1.5*1.3 | 2.5*1.5*1.7 | 3*1.8*2 | 3*1.6*2.1 | 3.5*1.8*2.1 | 3.5*2*2.8 | 4*2.2*3 |
| Weight(kg) | 300 | 340 | 480 | 640 | 1000 | 1300 | 3300 | 3500 | 4500 | 4800 | 9500 | 9800 |
Our products are sold all over the world, you can rest assured.
