Brief Introduction:
The European version of the large caliber counterattack is based on market demand to develop more advanced crushing equipment!It can show incomparable performance in coarse crushing, medium crushing, fine crushing and other operations.European impact crusher is mainly used in metallurgy, mining, cement, chemical industry, refractory materials and ceramics and other industrial sectors. It is widely used in highway construction, water conservancy engineering, construction gravel, machine-made sand processing and other fields. It is very suitable for coarse crushing, medium crushing and fine crushing of various soft and medium hard ores.
1. Advanced technology and unique design
The machine adopts heavy manufacturing technology, advanced manufacturing materials, heavy rotor design and strict detection means to ensure high-quality rotor. At the same time, the unique plate hammer fixing device makes the plate hammer more reliable.
2. Semi automatic operation, simple and fast maintenance
The hydraulic control system can quickly adjust the size of the discharge port and the discharge granularity through the hydraulic device; the automatic hydraulic top opening device can quickly complete the replacement of the plate hammer and other vulnerable parts, and reduce the downtime and maintenance time.
3. Cast steel structure, high bearing capacity
The bearing pedestal of this series of impact crusher adopts integral cast steel structure to ensure the stability of machine operation; larger size bearing is selected to make it have higher bearing capacity.
4. Simplify the process flow, widely used
Two cavity crushing, in the coarse crushing operation, can simplify the process flow; three chamber crushing, in the fine crushing, ultra-fine crushing operation performance is extraordinary. The two types of cavities can meet the crushing requirements of most coarse, medium and fine crushing operations.
Woorking principle:
This equipment is a kind of crushing machine which uses impact energy to crush materials. When the material enters the action area of the plate hammer, it is broken by the high-speed impact of the plate hammer, and is thrown to the impact device installed above the rotor for re crushing, and then rebounds from the impact lining plate back to the plate hammer action area for re crushing. This process is repeated until the material is crushed to the required size and discharged from the lower part of the machine. Adjusting the gap between the impact frame and the rotor frame can change the particle size and shape of the material. The spring safety device is adopted behind the impact plate. When the non broken materials enter the crushing chamber, the front and rear impact frames retreat, and the non broken materials are discharged from the machine
.Feature:
1. Improved adjustment device for easy operation.
2. Adopt high-abrasion manufacturing materials with optimized design manufacturing process.
3. The three-chamber crushing of the device is ideal for fine crushing and ultra-fine crushing operations.
4. The two chambers of the equipment are broken ,which can simplify the process when roughing and crushing.
5. Heavy-duty rotor design and strict testing methods ensure the rotor quality is durable.
Technical parameters:
| Model | PFC1011 | PFC1313 | PFC1316 | PFC1516 | PFC1520 |
| Production(t) | 136-181 | 136-272 | 136-400 | 454-544 | 544-726 |
| Motor(kw) | 160 | 220 | 315 | 500 | 630 |
| Feed opening size(mm) | 800x1130 | 1099x1238 | 1099x1645 | 1321x1651 | 1321x2057 |
| Maximum feed(mm) | 600 | 700 | 850 | 864 | 900 |
| Rotor(mm) | Φ1040x1100 | Φ1270x1220 | Φ1270x1626 | Φ1549x1626 | Φ1549x2032 |
| Number of hammers | 3/4 | 3/4 | 3/4 | 3/4 | 3/4 |
| Weight(kg) | 9252 | 13970 | 17463 | 25260 | 30532 |
