Introduce:
Automatic batch circulation low-temperature grain dryer was imported from Italy and jointly developed. At present, it is an advanced grain drying equipment.
The drying industry expects the grain dryer equipment manufacturing industry to adjust the product structure according to the requirements of high quality, low energy consumption and environmental protection, further strengthen the basic research and consolidate the foundation of application research and development.
In terms of technology, we should strengthen the research on automation, testing, manufacturing technology and material appearance design. In application research and development, we should not only pay attention to international exchanges and cooperation, but also pay attention to the protection of intellectual property rights; we should not only pay attention to the development of new technologies and new application fields, but also pay attention to the innovation and innovation of traditional technology and traditional application fields.
The mobile circulation grain dryer is mainly composed of three parts: shaft type, heating system and power generation equipment system.
At the same time, it is equipped with hub, distribution board, power supply and fuel, which can be moved and operated anytime and anywhere.
The control panel is simple and intuitive, easy to operate, safe and reliable.
The mobile batch circulation grain dryer integrates foreign technology, through the reasonable layout and distribution of all parts of the heating system, the drying efficiency is high and the variety of dried grains is complete.
Start the machine and start the loading screw lifting. The grain is added into the shaft container through the spiral lifting feeder. After the container is filled, the drying stage begins.
Gradually open the recovery shutter, start the burner, start the drying stage, and continuously sample and test the grain humidity. After automatic completion, cool and unload grain.
After completion, turn off the main motor and disconnect the power supply of the distribution board. The whole process is automatic and orderly, and the operation is simple.
Advantage:
1. It has strong adaptability and can be used for drying various kinds of grain.
2. The grain is dried thoroughly and evenly, and the dried grain can be directly stored in the warehouse.
3. The unit heat consumption is low, which can ensure the quality of the grain after drying without pollution.
4. The top-level combustion technology is adopted to make the temperature of the dried grain into the machine uniform and stable, and will not cause the grain to catch fire due to the high local temperature.
5. The design of the rotating parts is reasonable and stable, and the performance is good. It fully conforms to the national standard standard, and has protective devices and safety signs.
6. Reliability the equipment has high degree of automation and can work for a long time without supervision.
Technicai data:
| Model | YM-75 |
| Silo capacity(m³) | 10 |
| PTO absorbed power(HP) | 30 |
| Install electrical power(KW) | 15.4 |
| Fan air flow(m³/H) | 11000 |
| Maximum thermal power(Kcal/H) | 330000 |
| Holes in the silo wall(MM) | 1.5-2.5 |
| Weight(KG) | 2150 |
| Weight with exchanger(KG) | 2480 |
| FueL tank capacity (L) | 250 |
| Transport overall sizes(CM) | 455*226*246 |
Coarse grain is relative to the refined rice and white flour that we usually eat. It mainly includes barley, sorghum, oats, buckwheat, wheat bran and various dry beans, such as soybean, green bean, red bean, mung bean, etc. coarse grain should be processed after harvest, which requires the use of coarse grain dryer.
Our products are sold all over the world, you can rest assured.
