Introduce:
Automatic batch circulation low-temperature grain dryer was imported from Italy and jointly developed. At present, it is an advanced grain drying equipment in China, which is easy to move and does not pick the site. There is no odor, dust, pollution and noise in the drying process. After drying, the grain will not change its flavor, color, and nutrition, and it will not lose its nutrition.
Automatic mobile grain dryer, temperature automatic monitoring, high thermal efficiency. Hydraulic lifting, adjustable at any time, flexible. Indirect fire system heat exchanger to avoid any contamination. It is safer and more reliable to increase the automatic screening and dust removal of the cyclone dust removal system, and cooperate with the electronic and mechanical safety devices for remote monitoring and automatic control of the production process. This equipment is mainly suitable for all kinds of crops, such as corn, rape grain, wheat, grain, soybean, sunflower, pea, soybean, etc.
The mobile grain dryer is mainly divided into drying room and control room, with good mobile function. In the drying room of the dryer, the design of the dryer adopts the screw mixer, which can dry the grain in all directions. Improve the drying efficiency of grain and save drying time. The control cabinet includes heat separator, fan, cooling air duct, etc. Drying room and control cabinet are ventilation pipes like understanding to complete the whole drying process of grain.
Advantage:
1. Low maintenance cost, completely independent installation, no need for civil engineering, available power or tractor, low fuel consumption and easy to move.
2. Mechanized continuous operation, stable performance, convenient operation, saving civil engineering investment.
3. It has strong adaptability and can be used for drying various kinds of grain.
4. Waste heat recovery and utilization to reduce energy consumption.
5. The grain is dried thoroughly and evenly, and the dried grain can be directly stored in the warehouse.
6. The unit heat consumption is low, which can ensure the quality of the grain after drying without pollution.
Technicai data:
| Model | YM-120 |
| Silo capacity(m³) | 15 |
| PTO absorbed power(HP) | 60 |
| Install electrical power(KW) | 22 |
| Fan air flow(m³/H) | 28000 |
| Maximum thermal power(Kcal/H) | 600000 |
| Holes in the silo wall(MM) | 1.5-2.5 |
| Weight(KG) | 3600 |
| Weight with exchanger(KG) | 4100 |
| FueL tank capacity (L) | 380 |
| Transport overall sizes(CM) | 510*248*258 |
Soybean dryer is widely used in oil crops and grain post-processing operations in various regions, and is suitable for drying oil crops such as soybean, sunflower seeds, rapeseed, peanut and other oil crops in various regions.
It can satisfy the drying operation in various environments, and do it at any time and anywhere. According to the user's requirements, the diversified drying operation is carried out for different humidity grain drying requirements, so as to achieve a wider range of users.
