Application:
This machine is widely used in quartz, recrystallization, calcite, potash feldspar, talc, marble, limestone, dolomite, fluorite, lime, activated clay, activated carbon, bentonite, kaolin, cement, phosphate rock, gypsum, graphite, glass, manganese ore, titanium ore, copper ore, chromite, refractory, thermal insulation material, coal coke, coal powder, carbon black, pottery, bone powder, titanium dioxide powder High fine milling of more than 300 kinds of materials in non flammable and explosive mineral, construction, chemical industry, chemical fertilizer and other industries with Mohs hardness below 9.3 and humidity below 6%. The particle size of finished products is in the range of 60-325 mesh (0.125 mm-0.044 mm), and the fineness of a few materials can reach 1000 mesh (0.013 mm) as required.
Feature:
1. It can form an independent production system from block crushing to finished product packaging.
2. The passing rate of grain size of the finished product grinded by high and fine grinding machine can reach more than 99%, which is beyond the competence of other mills.
3.Electromagnetic vibration feeder is used to feed evenly, easy to adjust, small volume, light weight, saving oil and electricity, and convenient maintenance.
4. Centralized control is adopted in the electrical system, and the advanced model selection can realize unmanned operation in the main engine room.
5. The transmission device of the main engine adopts sealed reducer, which has stable transmission, reliable operation and no oil leakage.
6. The blade rest of the main engine is always in contact with materials during operation, so the blade carrier is composed of upper and lower parts. After the lower seat is worn, the conn.
Technical parameter:
| Model | 3R1510 |
| Feed size(mm) | <15 |
| Finished partical size(mm) | 0.125-0.044 |
| Different material fineness shift production(t) | 0.5-8 |
| Speed of central shaft (r/min) | 280 |
| Grinding ring inner diameter(mm) | 495 |
| Grinding roller diameter(mm) | 150 |
| Grinding roller height(mm) | 100 |
| Host motor | y160m-6-7.5 |
| Fan motor | y132s-2-5.5 |
| Analyzer motor | y90L-6-1.1 |
