Hydraulic 3.5*3.3*3.55m 380v Wood Packing Machine

Hydraulic 3.5*3.3*3.55m 380v Wood Packing Machine

  • High Light

    3.55m wood packing machine

    ,

    380v wood packing machine

    ,

    3.55m hydraulic packing machine

  • Place Of Origin
    China
  • Brand Name
    Yamei
  • Voltage
    380v
  • Power
    15kw
  • Weight
    4500kg
  • Dimension(L*W*H)
    700*480*250mm
  • Weight Of Bale
    20-25kg/bale
  • Certification
    CE
  • Place of Origin
    Henan, China
  • Brand Name
    YAMEI
  • Certification
    CE
  • Model Number
    QZD-1200
  • Minimum Order Quantity
    1 SET
  • Price
    $18,500.00 - $19,000.00 / Set
  • Packaging Details
    Packaging Details: wood case for sawdust baler machine
  • Delivery Time
    7-30day
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    60 Set/Sets per Month

Hydraulic 3.5*3.3*3.55m 380v Wood Packing Machine

Hydraulic Sawdust Packing Machine Gather shavings together to save 80% of space



The machine can be widely used in the compressed packaging of light foam loose materials such as cotton, chemical fiber, hemp, wool, grass, medicinal materials and recycled materials for convenient storage and transportation.



This machine is low failure rate and stable performance,it is can be normal work in low miosture content condition which will not be press in some fatory. Very suitable for using with auto-feeding system.It can be specially made according to customer's requirement.

It adopts Hydraulic transmission control system,high automatic,stable speed,high yield,easy operation,widely used in sawdust, shaving,cottonseed hull, peanut shell, corn cob press and packing, one-time compressed into a bag,convenient storage,which can greatly reduce the trandportation cost,what is more,it will be loose easily after press.it also can be used in Green building material, agricultural fertilizer etc.



Just compressed material, this product USES hydraulic motor rotation driven oil pump jobs when at work, in the extraction tank pressure oil, hydraulic oil delivery, spread to the hydraulic oil cylinder, driving the oil cylinder piston rod lateral movement compression in container of various materials, at last, by extrusion press side cylinder, good compression bag piece from the discharging mouth extrusion, finished bag piece of homework.



Feature



1. High auto-control system ,workfore saving



2. High yield,stable speed



3. Auto-weighting,can be adjusted according to your requirement



4. Auto-feeder,easy operation



Applicable Industries:

Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, farms, restaurant, HOME USE, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company



Technical data

Model QZD-1200
Voltage 380v-50hz
Power 17.2kw
Outside size 3.5*3.3*3.55m
end product size 750*480*250mm
end product weight 15-25kg
shift capacity 1000-1500kg
weight 4500kg
Auto-feeder 4-6m



Hydraulic 3.5*3.3*3.55m 380v Wood Packing Machine 0

Matters needing attention and maintenance of baling machine:



1. Pay attention to the normal maintenance of the machine;



2. Regular maintenance and oil filling to ensure the matching of No. 46 hydraulic oil;



3. Tap the power supply according to the diagram, do not mix the three phase and two phase;



4. The hydraulic oil in the pumping station shall not be lower than the normal scale, nor exceed the scale limit;



5. The pressure gauge should be kept under 18MPa when normal;



6. Ensure safety and specially-assigned operation; strictly prohibit squeezing inflammable and explosive dangerous goods;



7. Any discrepancy between the annex and this note does not belong to the three guarantees.

Hydraulic 3.5*3.3*3.55m 380v Wood Packing Machine 1

frequently asked question



Hydraulic baler can't press



1. Check the hydraulic oil

2. Check whether the pressure regulating valve is slack

3. Check the oil pump



How does hydraulic baler solenoid valve not work



Open cleaning with diesel oil
