6m Wood Packing Machine

6m Wood Packing Machine

  • High Light

    6m Wood Packing Machine

    ,

    4500kg Wood Packing Machine

  • Place Of Origin
    China
  • Brand Name
    Yamei
  • Voltage
    380v
  • Power
    15kw
  • Weight
    4500kg
  • Dimension(L*W*H)
    700*480*250mm
  • Weight Of Bale
    20-25kg/bale
  • Certification
    CE
  • Place of Origin
    Henan, China
  • Brand Name
    YAMEI
  • Certification
    CE
  • Model Number
    QZD-1200
  • Minimum Order Quantity
    1 SET
  • Price
    $18,500.00 - $19,000.00 / Set
  • Packaging Details
    Packaging Details: wood case for sawdust baler machine
  • Delivery Time
    7-30day
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    60 Set/Sets per Month

6m Wood Packing Machine

Baling Machine Is Widely Used For Packing Cotton And Shavings With Little Damage To Materials



Shaving packing machine is also known as vertical packing machine,sawdust shaving packing machine,which adopt many patent technology,compared with other similar products,it has a reasonable design structure,high efficientcy can be get more than 50 bags per hour.It is also the fastest and highest autimation equipment in our domestic.



This machine adopts hydraulic transmission and control system.With high degree of automation, stable speed, high output, simple operation.Used for compressed packing of loose materials, sawdust, shavings, cottonseed shells, peanut shells, silver leaves, wood chips, ginkgo leaves, corn cob chips and other materials, one-time compression bagging is convenient for storage and reduces transportation cost.After compression, easy to take out loose, can also be used for environmental building materials, agricultural fertilizer, mushroom cultivation.Compression chamber size and block shape can be determined according to user requirements.



general-purpose hydraulic baling press for peanut shells, corn cobs, wood shavings, wood chip, gingko leaf, leaf tobacco, rice husk, straw, grass, paper, cotton, garment, plastics, wool, recyclable waste, waste bin, paper board, yarn, tobacco leaf, plastic, cloth, woven bags, knitted velvet, waste plastic bags all light bulbs, loose soft materials such as compression packaging materials, and greatly reduce the volume, increase the density, save up to 80% of the stack space, convenient transportation and storage.



Technical data

Model QZD-1200
Voltage 380v-50hz
Power 17.2kw
Outside size 3.5*3.3*3.55m
end product size 750*480*250mm
end product weight 15-25kg
shift capacity 1000-1500kg
weight 4500kg
Auto-feeder 4-6m

6m Wood Packing Machine 0

Matters needing attention

1. Please confirm the power used by the machine and do not plug in the wrong power.The machine adopts three - phase four wire system. The wire is earthed zero wire for leakage protection.

2. Do not touch the heating sheet directly with your hands.

3. Do not flush the machine with water. Operators should not work barefoot when the workplace is wet.

4.Remember to unplug the machine when not in use.

5.Don't change the parts of the machine at will.

6. Main parts should be lubricated with oil frequently.



Correct use of machinery and equipment, careful implementation of the maintenance system and strict observance of safe operation rules are the necessary conditions to extend the service life of machines, improve production efficiency and ensure safe production.To this end, it is recommended that users establish maintenance and safe operation procedures, operators should be familiar with the machine structure and operation procedures, but also must pay attention to the following points:

(1) High quality anti-wear hydraulic oil shall be strictly used when adding hydraulic oil into the oil tank. It must be filtered strictly and always keep enough oil. In case of shortage, the oil shall be filled immediately.

(2) The oil tank should be cleaned and replaced with new oil every half a year, but the first cleaning and filtering oil should not exceed one month. The new oil used once is allowed to be used again after strict filtration.

(3) The lubrication points of the machine shall be filled with lubricating oil at least once per shift as required.

(4) The sundries in the material box should be cleaned in time.

(5) Those who have not studied and do not understand the structure, performance and operation rules of the machine shall not operate the machine without authorization.

(6) In case of relatively serious oil leakage or abnormal phenomena occurring in the operation of the machine, it shall stop the operation immediately to analyze the causes and troubleshoot the machine. It shall not be forced to operate with diseases.

(7) During the operation of the machine, it is not allowed to repair or contact the moving parts. It is strictly prohibited to press materials in the material box with hands or feet.

(8) Pump, valve, pressure gauge adjustment, must be experienced technical workers, if found fault with the pressure gauge, should immediately check or update the table.

(9) The user shall make detailed maintenance and safe operation rules according to the specific conditions.
