Introduction of wood poder mill:
Superfine wood powder mill is used for light body materials, fiber materials, brittle materials and ductile materials such as special difficulty grinding milling equipment, are our latest products, the machine improves the fine degree of the finest of wood powder can reach 100-325 mesh, solve the gap of ultrafine powder on the market, at the same time in the process of pulverizing, can cent gives two level area (that is, the common grade and superfine grade), equipment design is reasonable, low loss, low noise, no pollution, simple operation, once listed on the wood powder machine market occupy the leading position.
Technical Parameters of wood powder mill
| Model NO. | 550 | 850 | 950 | 1000 |
| (water-cooling double chamber) | ||||
| Power (kw) | 11-18.5 | 22-30 | 45-55 | 90-110 |
| Rotate speed (r/min) | 3600 | 3300 | 2900 | 2900 |
| Number of cutter | 36 | 72 | 96 | 192 |
| Degree of fineness (mesh) | 10-500 | 10-500 | 10-500 | 10-500 |
| Feeding particle size(mm) | <30-35mm | <30-40mm | <40-50mm | <50-60mm |
| Material Moisture | <6% | <6% | <6% | <6% |
| Weight(kg) | 1600 | 2600 | 3800 | 9200 |
| Dimension(m) | 4.5×1.8×3.5 | 7×2.5×4.3 | 7×2.8×4.3 | 12*3.5*5.5 |
Working principle of wood powder mill:
During the operation, the materials to be crushed are added into the machine from the feeding hopper on the side of the machine cover. Relying on the grinding roller device suspended on the plum blossom frame of the main engine, it rotates around the vertical axis and rotates itself. Due to the centrifugal force during rotation, the grinding roller swings outward and presses tightly on the grinding ring, so that the shovel picks up the material and sends it between the grinding roller and the grinding ring, and the crushed material is reached due to the rolling and rolling of the grinding roller The purpose of the material.
Characteristics of wood powder mill:
1. Energy saving: under the condition of the same output and fineness index, the energy consumption of pulverized sawdust materials is only about 1/3 of that of air grinding;
2. Good fineness index: when pulverizing sawdust materials, the fiber is good, and the fineness can reach 200~350 mesh.
3. equipped with a graded impeller stepless governor, do not need to stop the product size can be adjusted, and fine powder can be all recovered,
not pollution of the environment.
4. Dust removal effect fully meets the national dust emission standard.
5. The grinding device adopts overlapped multistage sealing, with good sealing performance.
6. Grinding part of the wear parts with alloy wear resistant material, long service life.
7. Stable mechanical performance, able to work continuously for 24 hours.
After Sales Service
1. One year for machinery warranty.
2. We have the cheap spare parts supply.
3. We can sent engineer to install and maintain on site.
FAQ
1)Are you a factory or trade company?
We have our own factory as an international supplier, a professional manufacturer and a general international trader.
2) How can I trust your company?
1.Henan Wheat Import And Export Company Limited, established in 2005, located in Zhengzhou City--Capital of Henan Province, the center of China mainland.
2.We have special QC department, testing every single equipment, from voltage to appearance, our workers will inspect strictly in order to supply the best and most stable machine for our customers.
3.Our equipment are strictly designed and produced according to CE standard, we care for every details and the quality.
3) How long is your delivery time?
Generally it is 30 days after received your deposit.
4) Is your price competitive?
We can provide the highest quality machines at the best price.
Our products are sold all over the world, you can rest assured.
